3/8" PNEUMATIC DOUBLE DIAPHRAGM PUMP, UP03, PIVOT SERIES,CONDUCTIVE PP-PP-PTFE-HYTREL, BSP-LAT&CEN-THREATED
3/8" PNEUMATIC DOUBLE DIAPHRAGM PUMP, UP03, PIVOT SERIES,CONDUCTIVE PP-PP-PTFE-HYTREL, BSP-LAT&CEN-THREATED
Air operated double diaphragm pumps for dosing, spraying, transferring, evacuating and distributing a wide variety of fluids. SAMOA offers a wide range of material options for chemical compatibility and to withstand abrasion, temperature and fatigue caused by demanding conditions. UP03 Non-Metallic pumps make the difference through: · HIGHER EFFICIENCY. Maximum fluid flow with reduced air consumption. · INCREASED RELIABILITY. No stall, no icing, reliable start-up and longer air valve and diaphragms life. · MAXIMUM VERSATILITY. Aluminium and Stainless Steel pumps with a wide range of diaphragms, seats and balls options offer broad fluid and application compatibility. Highly suitable for outdoors and general applications with presence of abrasives. · EASY SERVICING. Simplified maintenance and cleaning. The pump is held together by carriage bolts and nuts allowing to accomplish a much faster tear down and rebuild. · COMPACT DESING. Ready to meet any OEM application needs. · CONNECTIVITY. Can be configured to connect a Smart Pump-Controller System to actuate, control and monitor your pumps. Instruction books: 855878 and 855879.
| Pump size | 3/8" |
| Pressure ratio | 1:1 |
| Target product type | Pivot Series Diaphragm Pumps |
| Maximum free flow delivery | 31 l/min (8,2 gal/min) |
| Air pressure operating range | 1,5-7 bar (20-100 psi) |
| Solids in suspension maximum size | 1,6 mm (0,06 ") |
| Maximum dry suction head | 3 m (10 ft) |
| Maximum wet suction head | 7 m (23 ft) |
| Delivery per cycle | 0,08 l (0,02 gal) |
| Fluid inlet | 3/8" BSP (F) |
| Fluid outlet | 3/8" BSP (F) |
| Air inlet | 1/4" NPSM (F) |
| Air exhaust port | 1/2" NPT (F) |
| Sound level | 75 dB |
| Certification | CE |
| Central body & Air chambers material | Conductive polypropylene |
| Fluid ports / Location | 3/8" BSP central and lateral threaded |
| Fluid chambers & Manifolds material | Polypropylene |
| Hardware Bolts & Inserts material | Stainless steel |
| Diaphragms type & material | Hytrel |
| Valve seats material | Polypropylene |
| Valve balls material | PTFE |
| Wetted materials | Polypropylene, Hytrel |
| Accessories for UE Pumps | No |
| Weight | 1,8 kg (4 lb) |
