PM80 series air operated piston pumps. Ultra high pressure double acting pump. 200:1 pressure ratio pump designed for use in oil and gas wells in wireline and plug valve applications. In wireline applications, these pumps are used to seal against the well external pressure, preventing the tube from collapsing as the well is perforated. In plug valve applications, these pumps pump heavy grease into “christmas tree valves”, sealing any gas leak. Features: · 8” air motor effective diameter for maximum power. · Well proven, no stall and no ice forming air motor. · Reinforced construction, to stand up to 1.200 bar pressure. · Reliable fluid seals. · Divorced designed with steel covers to protect pump rod from tough environment Air consumption at 5 bar (70 psi) air pressure, NLGI-2 grease at 20 °C (68 °F) and 40 cpm. Noise level measured at 1 m (3.3’) from the pump, 6 bar (87 psi) air pressure and free delivery. WARNING: SAMOA 8” 200:1 pumps deliver pressures up to 1.200 bar (18,000 psi) which is in excess of the rated capacity of the accessories normally used with lubrication equipment. These 200:1 pumps can only be used in permanently installed systems where the pump is connected directly to the piping with a proper rating for the application. Instruction book: 853831.
