PUMPMASTER 45 - 11:1 RATIO INK PNEUMATIC PUMP, 200 KG DRUM WITH PNEUMATIC PUMP HOIST AND GRAVITY INDUCTOR PACKAGE
Ref.: 542925.270
PUMPMASTER 45 - 11:1 RATIO INK PNEUMATIC PUMP, 200 KG DRUM WITH PNEUMATIC PUMP HOIST AND GRAVITY INDUCTOR PACKAGE
PM45 - 11:1 ratio ink pumps 542 011 fixed to the single lip follower
plate and the weight of the air motor, pump, and mounting bracket
maintains pump prime. The unit is very robust and easy to use. It
includes a pneumatic valve wich controls the pump lift up and down
movement Instruction book: 854807.
Technical data
Documentation
More information
| Subtype | Pump on 200 kg drum with pneumatic pump hoist and gravity inductor package |
| Fluids | Others |
| Target product type | Shovel Intake Piston Pumps |
| Model | SP-I |
| Application | Automotive Repair & Maintenance, Industrial Processes, Industrial Lubrication |
| Pressure ratio | 11:1 |
| Delivery | 2,2 kg/min (4,8 lb/min) |
| Delivery per cycle | 0,18 l (0,05 gal) |
| Maximum free flow delivery | 3,1 kg/min (6,8 lb/min) |
| Air pressure operating range | 1,5-7 bar (20-100 psi) |
| Air consumption | 600 NL/min (21,2 scfm) |
| Maximum outlet pressure | 77 bar (1120 psi) |
| Air motor effective diameter | 115 mm (4,5 ") |
| Air motor stroke | 100 mm (4 ") |
| Air inlet | 1/2" BSP (F) / 1/2" NPT (F) |
| Fluid Inlet | 2" BSP (M) |
| Fluid inlet type | Ball check |
| Fluid outlet | 3/4" BSP (F) / 3/4" NPT (F) |
| Wetted materials | Acetal, Viton, Carbon steel, Cast iron, Bronze, UHMWPE |
| Pump tube material | Carbon steel |
| Tube height | 320 mm (12,6 ") |
| Pump Mounting | 205 l (55 gal) drum bung mounted |
| Total height | 1043 mm (41 ") |
| Sound level | 80 dB |
| Weight | 22 kg (48,5 lb) |
Kit components
| Code | Product |
|---|---|
| 391020.270 | SINGLE POST AIR OPERATED PUMP HOIST FOR INK PISTON PUMPS, 200 KG DRUMS |
| 542011 | PNEUMATIC PISTON INK PUMP, PUMPMASTER 45, PM45 - 11:1 |
| 854454 | FOLLOWER PLATE ADAPTOR FOR PUMP HOIST, GRAVITY INDUCTOR, PM45 Y PM60 |
